S2000 Micro Sprinler Rivulis

S2000 Micro Sprinklers

Rivulis S2000 Micro Sprinkler

The Rivulis S2000 Micro Sprinklers and Rivulis S2000 Flow Regulated Micro Sprinklers are ideal choices for a wide range of applications including short-term crops such as vegetables and long-term crops such as orchards. Built to last, the Rivulis S2000 Micro Sprinkler lines incorporate solid (strong) bridges, built-in anti-insect protection, and a wear resistance design. In addition to the standard features, the Rivulis S2000 Micro Sprinkler line can be configured with add-on features like the spinner with integral range limiter for a smaller wetting diameter around young trees.
The Rivulis S2000 Flow Regulated Micro Sprinkler has the added feature of flow regulation extending the use of the sprinklers in applications with sloping fields or long lateral runs.
The Rivulis S2000 Micro Sprinkler can be installed in different ways including plastic stake, metal stake, and hanging. Regular or Flow Regulated Micro Sprinkler. Flow regulation option Anti-insect protection Range limiter options Sprinkler position: upright Installation: Stake (plastic or metal) and hanging.
The Rivulis S2000 Micro Sprinkler is also simple to maintain because it can be easily disassembled, allowing for both field maintenance and replacement of individual parts. You can always count on the flexibility and reliability of the Rivulis S2000 Micro Sprinkler to deliver the results you need.

S2000 leaflet

The Rivulis S2000 Micro Sprinklers and Rivulis S2000 Flow Regulated Micro Sprinklers are ideal choices for a wide range of applications including short-term crops such as vegetables and long-term crops such as orchards.

  • More

The Rivulis S2000 Micro Sprinklers and Rivulis S2000 Flow Regulated Micro Sprinklers are ideal choices for a wide range of applications including short-term crops such as vegetables and long-term crops such as orchards. Built to last, the Rivulis S2000 Micro Sprinkler lines incorporate solid (strong) bridges, built-in anti-insect protection, and a wear resistance design. In addition to the standard features, the Rivulis S2000 Micro Sprinkler line can be configured with add-on features like the spinner with integral range limiter for a smaller wetting diameter around young trees.
The Rivulis S2000 Flow Regulated Micro Sprinkler has the added feature of flow regulation extending the use of the sprinklers in applications with sloping fields or long lateral runs.
The Rivulis S2000 Micro Sprinkler can be installed in different ways including plastic stake, metal stake, and hanging. Regular or Flow Regulated Micro Sprinkler. Flow regulation option Anti-insect protection Range limiter options Sprinkler position: upright Installation: Stake (plastic or metal) and hanging.
The Rivulis S2000 Micro Sprinkler is also simple to maintain because it can be easily disassembled, allowing for both field maintenance and replacement of individual parts. You can always count on the flexibility and reliability of the Rivulis S2000 Micro Sprinkler to deliver the results you need.

 S2000 Micro sprinkler leaflet

S2000 Micro Sprinkler complete assembly [50 un pack]

Rivulis Plastro
101042546xxx+201000259+257
ex Shipping kg
    Delivery time:6-10 Days
Add to cart

provides flexible installation options and numerous
additional features. Spinner with detachable range limiter

S2000 Micro Sprinkler complete assembly

Flow rates: 51  to 102 l/h - [13.5 gph to 27 gph]
Minimum working pressure: 2.0 bar [29 psi]
Recommended filtration: 130 to 200 Micron [80 to 120 mesh]
Applications: Under-tree irrigation.

S2000 Micro  Sprinkler complete assembly includes:
- Blue connector From a PE pipe to a 4x7 mm mini tube
- 4 x 7 mm by 60 cm PE mini tube
- 35 cm Stake (Kantal)
- Integral Anti Insect and ant devise

S2000 Micro sprinkler leaflet

  • More

Main features:
- Low to moderate irrigation application rate with gentle
  droplets - prevents run-off on non-penetrable soils
- Moderate to wide wetting range
- Uniform water distribution pattern
- Easy to take-apart for field maintenance and replacement of
  individual parts
- Spinners for different applications
- Available with anti-insect snap-fit cup
- Option: Rondo fan sprayer on single bridge with adjustable
  deflectors for 90˚, 180˚, 360˚ wetting patterns
- Protected against UV degradation
- Resistant to chemicals and fertilizers


Specifications:
- Flow rates: 51 lph to 102 lph - [ 13.5 Gph to 27 Gph]
- Recommended operation pressure: 2.0 bar [29 Psi]


Versatility - a wide choice of models and applications:
Single or double bridge frame
Installed in upright or inverted position
11 colour-coded nozzle sizes
3 assembly options with bayonet-mount nozzles:
- 3/8" thread [ 10 mm ] x conic female inlet

Applications:
- Under-canopy irrigation in orchards
- On metal rods for vegetables irrigation
- In greenhouses, inverted overhead

Rondo leaflet

Rondo design technical data

S2000 Flow regulated micro sprinkler assembly [ 50 un pack]

Rivulis Plastro
101042546+201000259+257
ex Shipping kg
    Delivery time:6-10 Days
Add to cart
S2000 Flow regulated  /Micro Sprinkler complete assembly.

 Flow rates: 24  to 95 l/h - [4.8 gph to 9.7 gph]
Minimum working pressure: 2.0 bar [29 psi]
Recommended filtration: 130 to 200 Micron [80 to 120 mesh]
Applications: Under-tree irrigation on sloping terrain or where long laterals are required.

S2000 Flow regulated Micro  Sprinkler complete assembly includes:

-  Blue connector From a PE pipe to a 4x7 mm mini tube
- 4 x 7mm by 60 cm PE mini tube
- 35 cm Stake (Kantal)
- Integral Anti Insect and ant devise

 S2000 Micro sprinkler leaflet

  • More

Main features:
Ensures constant flow rate under the most challenging topographical conditions - Low irrigation application rate with gentle droplets.
Provides a constant flow rate over a wide pressure range.  Rondo Flow  Regulated micro sprinkler  (RFR Plastro) whole standard set.

 RFR Complete standard set includes: Minimum order 50 units: RFR mini sprinkler, upright position spinner, 35 cm [14"] Stabilizing stake, 4x7 [9/32"] PE tube and coupler that feet any low density PE pipe.

Flow rate

Nozzle

Wetting diameter

23 l/h [4.8 gph]

= black

0.85 mm  [0.033"]

4.0 m [13 feet]

30 l/h [5.2 gph]

= blue

1.05 mm  [0.041"]

5.5 m [19 feet]

41 l/h [6.0 gph]

= dark blue

1.10 mm  [0.043"]

5.7 m [19 feet]

53 l/h [6.8 gph]

= green

1.20 mm  [0.047"]

6.4 m [21 feet]

70 l/h [8.0 gph]

= red

1.40 mm  [0.055"]

8.0 m [26 feet]

95 l/h [9.7 gph]

=  white

1.60 mm  [0.063"]

8.4 m [28 feet]











RFR more detailed information

Rondo RFR flow regulated leaflet

Design technical data Rondo flow regulated

<< Back to products group page

2.8 mm Quick Punch for S2000, Rondo, Tornado 4x7 mm connectors

Rivulis Plastro
101003350
ex Shipping kg
    Delivery time:6-10 Days
Add to cart

Mechanical Product

2.8 Punch tool

Quick punching tool
Professinal puncher for S2000, Rondo, Tornado 4x7 mm connectors and 2.8 mm holes for 12, to 22 mm pe tubes 0.11" holes for 1/2"  to 7/8" po
lytubes.

7x4_quick_multi_tool_tali_almagor_240

Supertali7x4
ex Shipping kg
    Delivery time:6-10 Days
Add to cart
Super tali inserter for 7mm x 4mm microtube assemblies

Super tali semi automatic insertion tool.
inserter for various fittings and accessories inside 7x4 microtube, for ldpe and soft pvc microtubes.

7 mm microtube external diameter, 4 mm microtube internal diameter,
